MODEL
|
BXH42
|
BXH42
|
|
Chipper Capacity
|
100mm
|
4″
|
|
Chipper Housing Opening
|
100x254mm
|
4″x10″
|
|
No. of Knives
|
4
|
4
|
|
Rotor Size
|
635 mm
|
25″
|
|
Feeding System
|
Self Feed/Pinch &Pull
|
Self Feed/Pinch &Pull
|
|
Size with Hopper Folded
|
1016Lx1067Wx1524H(mm)
|
40′”Lx42′”Wx60′”H
|
|
Hopper Opening
|
508×508 mm
|
20′”x20′”
|
|
|
||
|
Discharge Hood Rotation
|
360°
|
360°
|
|
Discharge Hood Height
|
1524 mm
|
60″
|
|
Structure Weight
|
195kg
|
430 LBS
|
|
Pump oil flow(L/min)
|
60L/min
|
60L/min
|
|
Max Pressure
|
20MPa
|
20MPa
|
|
Min. Operation Flow
|
14GPM
|
14GPM
|
|
Max Capacity Flow
|
24GPM(4″dia)
|
24GPM(4″dia)
|
|
Attach type
|
Skid steer Universal
|
Skid steer Universal
|
|
Flywheel
|
25″Diameter,80lbs.-1/2″Thick
|
25″Diameter,80Ibs.-1/2″Thick
|
|
w/extractor-wings
|
w/extractor-wings
|
|
|
Bed Blades
|
1 reversible
|
1 reversible
|
|
Drive
|
Direct
|
Direct
|
|
|
|
CLASS*Professional Grade
Weight 195 Kg
